Products:
This series of products are widely used in the primary crushing of various ores and rocks in the fields of mining, building materials, metallurgy, highways, railways, water conservancy, and chemical industries. They are suitable for crushing various materials with a compressive strength of not more than 350 MPa.
Technical Parameters:
Model | EM106J | EM116J |
Feeding Equipment | ||
Feeding Capacity（t/h） | 450 | 450 |
Hopper Volume（m³） | 5 | 3.5 |
Host Equipment | ||
Jaw Crusher | C106 | C116 |
Max feeding size（mm） | 600 | 700 |
Discharge opening adjustment range（mm） | 70-200 | 70-200 |
Crusher Weight（t） | 18 | 22 |
Crusher Power（kw） | 110 | 132 |
Main Belt | ||
Length x Width（mm） | 10000 x B1200 | 10000 x B1200 |
Unloading Height（mm） | 3000 | 3000 |
Power（kw） | 15 | 15 |
Whole Equipment | ||
Total Weight（t） | 34 | 39 |
Capacity（t/h） | 150-400 | 170-450 |
Power（kw） | 136（139） | 158（161） |
Transport Dimension (mm) | 14300 x 3400 x 3850 | 14300 x 3400 x 3850 |
